To test the real-life performance of a drive we use a mix of folder/file types and by using the FastCopy utility (which gives a time as well as MB/s result) we record the performance of drive reading from & writing to a 2TB Seagate FireCuda 510.

Transfer Details:

• Data file – 100GB.
• File folder – 50GB – 28,523 files.
• Steam folder – 120GB (5 games: BioShock Infinite, Crysis 3, Grand Theft Auto V, Skyrim, The Witcher3 Wild Hunt).
• Movie demos 8K – 21GB – (11 demos).
• Raw Movie Clips 4K – 16GB – (9 MP4V files).
• Audio Folder – 10GB – 1,483 files – (1479 @ MP3, 4 @ .FLAC files).
• Single large image – 5GB – 1.5bn pixel photo.
• 3D Printer File Folder – 4.25GB – (166 files – 105 @ .STL, 38 @ .FBX, 11 @ .blend, 5 @ .lwo, 4 @ .OBJ, 3@ .3ds).
• AutoCAD File Folder – 1.5GB (80 files – 60 @ .DWG and 20 @.DXF).

The EX400U 2TB drive averaged 1,802MB/s for the 9 file transfers in write mode, the fastest being the 2,684MB/s for the 4K folder transfer. When it came to reads, the drive averaged 2,430MB/s with the fastest being the 3,126MB/s for the 100GB data transfer. The drive topped the 3GB/s mark in four out of the nine read transfers and passed the 2GB/s mark in another two.
